Sensitech Ultra Datalogger Dry Ice

Food and industrial

Category: ,

Description

name of data logger
dry ice data logger

This new datalogger can be programmed with up to six temperature alarms, including MKT and duration. The integrated USB connector provides a fast and easy download of data and automatically generates a secure PDF report and encrypted data file when connected to a USB port on a PC.



temperature reading display of data logger
sample display alarmed of data logger



Introducing the TempTale® Ultra Probeless Dry Ice monitor – a compact USB temperature datalogger that can be placed directly into dry ice environments as low as -95ºC.



This new datalogger can be programmed with up to six temperature alarms, including MKT and duration. The integrated USB connector provides fast and easy download of data, and automatically generates a secure PDF report and encrypted data file when connected to a USB port on a PC. These files can be subsequently downloaded, viewed and archived in Sensitech’s TempTale Manager® Desktop (TTMD) software or ColdStream® Cold Chain Manager private cloud database application—built to comply with FDA 21 CFR Part 11 and EC Annex 11. Furthermore, the TempTale Ultra Probeless Dry Ice monitor meets IATA’s Dangerous Goods Regulations and thus requires no additional shipment labeling.



TempTale® Ultra Probeless Dry Ice Features



• Monitor temperatures as low as -95°C
• Place directly into dry ice environment in contact
with product
• 3-Point NIST traceable calibration certificate accessible
in TTMD or ColdStream software
• Large LCD screen provides clear indication of alarm status
and trip statistics
• Program up to six alarms, including MKT and Trip Duration
• Flashing LEDs clearly indicate Start/Stop modes and Alarm
status inside and outside of dry ice environments

• Download directly to PC via integrated USB connector
• Configurable PDF options such as, time zone, language
and PDF/A file format
• Add shipment information prior to shipping to display on
PDF report and in software when monitor is downloaded
• Write-protected flash drive for virus protection





TempTale Manager® Desktop Software



TempTale Manager® Desktop (TTMD) is a robust, multi-lingual, Windows-based software application used for configuring, downloading and archiving time and temperature data collected from TempTale temperature monitors. The power of TTMD software lies in its intuitive user interface that allows users to effortlessly analyze trip data in order to make high-quality shipment disposition decisions, and ensure that Standard Operating Procedures (SOPs) are delivering acceptable results.



ColdStream® Cold Chain Manager Software



ColdStream® Cold Chain Manager (CCM) is a validated, hosted and secure relational database application that is easily accessible via the Internet for query, reporting and analysis of stored data. ColdStream CCM provides centralized storage for time and temperature records in a secure, 21 CFR Part 11 compliant repository. The hosted database application enables robust cold chain data analysis, reporting, and opportunities for process improvement.



.
